Blade Terminal Red

The 0.25mm²-1.5mm² PVC insulated blade terminal with a 13.2mm x 2.3mm blade size is a reliable solution for connecting copper conductors in various electrical applications. Designed with high-quality electrolytic copper, it ensures excellent conductivity and durability. The PVC insulation offers protection in environments with temperatures ranging from -20°C to +80°C. Additionally, the blade terminal is tin-plated to prevent oxidisation and annealed to ensure optimum ductility, allowing for easier conductor insertion.

• Material: Made from electrolytic copper for superior conductivity.
• Surface Protection: Electrolytically tin-plated for oxidation resistance.
• Insulation: PVC insulation for temperature protection.
• Pin Size: 13.2mm x 2.3mm.
• Diameter: 3.9mm.
• Length: 23.3mm.
• Temperature Range: -20°C to +80°C.

Technical Specifications

Download Product Technical Data Sheet

• Type: Solderless copper terminals for copper conductors
• Nominal Cross Section: 0.25mm² - 1.5mm²
• Material: Copper
• Surface Protection: Tinned
• Colour Insulation: Red
• Insulation: Polyvinyl chloride (PVC)
• Flange Shape: Pin shape
• Sleeve Form: Short
