0.5mm² Pre-Insulated Crimp Bootlace Ferrule 8mm White

This end sleeve is designed to provide a secure and insulated termination for flexible copper conductors, ensuring reliable electrical connections in a variety of applications.

• Insulation: Made with polypropylene, this end sleeve offers excellent insulation and protection for the conductor. It is halogen-free and suitable for use within a temperature range of -20°C to +115°C.
• Material: Constructed from copper with a purity greater than 99.9%, ensuring high conductivity. The sleeve is electrolytically tin-plated to prevent oxidation and enhance durability.
• Ductility: Annealed to guarantee optimum ductility, allowing for easy introduction and secure crimping of the conductor.
• Colour: The end sleeve is white, which facilitates easy identification and colour-coding within wiring systems.

Technical Specifications

Download Product Technical Data Sheet

• Insulation: Polypropylene (PP)
• Colour of Insulation: White
• Material: Copper
• Surface Protection: Tinned
• Nominal Cross Section: 0.5 mm²
• Sleeve Length: 8 mm
• Construction Type: Standard

This end sleeve is ideal for use with conductors in the 0.3mm² to 0.5mm² range, providing a reliable and insulated connection that meets industry standards.
