16mm² Polyamide Pa6.6 Insulated Copper Tube Crimping Lug M8 Stud Black

The 16mm² Polyamide PA6.6 insulated copper tube crimping lug with an M8 stud is engineered for secure and reliable electrical connections. It features a robust Polyamide PA6.6 insulation sleeve and is designed to facilitate conductor insertion. The lug operates efficiently across a temperature range of -25°C to +115°C and is electroplated with tin to resist oxidisation. Additionally, it is manufactured from high-purity electrolytic copper and includes an inspection hole for verifying proper conductor insertion.

Technical Specifications

Download Product Technical Data Sheet

• Surface protection: Tinned
• Connecting angle: 180° (horizontal)
• Flange shape: Ring shape
• Colour insulation: Black
• AWG size: 6
• Material: Copper
• Bolt dimension (metric): 8
• Number of fixing holes: 1
• Insulated: Yes
• Nominal cross section: 16 mm²
• With sight-hole: Yes
• Slender flange model: No
