70mm² Copper lug M10 stud [Pack of 50]

This 70mm² copper tube crimping lug is designed to provide a reliable connection for high-performance electrical systems. It features an insulation sleeve that facilitates the easy introduction of conductors and is made from electrolytic copper with a purity greater than 99.9%. The lug is annealed to ensure optimum ductility, and electroplated with tin to prevent oxidation. Its operating temperature range spans from -50°C to +150°C, with a maximum voltage rating of 11kV.

Technical Specifications

Download Product Technical Data Sheet

• Surface Protection: Tinned
• Flange Shape: Ring shape
• Material: Copper
• Connecting Angle: 180° (horizontal)
• AWG Size: 00
• Bolt Dimension (Metric): 10
• Number of Fixing Holes: 1
• Nominal Cross Section: 70 mm²
• Slender Flange Model: No
• Insulated: No
• With Sight-Hole: Yes
