A-M Tube Crimping Lug Copper 95mm² 14mm Stud 25/Pack

This 95mm² copper tube crimping lug is designed for robust electrical connections. Made from high-purity electrolytic copper (greater than 99.9%) and annealed for optimal ductility, it features a tinned surface to prevent oxidation. The lug includes an insulation sleeve for easy conductor introduction and is rated for a maximum voltage of 11kV. It operates within a temperature range of -50°C to +150°C and is equipped with a ring-shaped flange and a sight-hole for secure and reliable connections.

Technical Specifications

Download Product Technical Data Sheet

• Type: Copper tube crimping lug
• Material: Copper
• Nominal Cross Section: 95 mm²
• Bolt Dimension (Metric): M14
• Flange Shape: Ring shape
• Conductor Category: Class 5 (flexible)
• Connecting Angle: 180° (horizontal)
• Surface Protection: Tinned
• Insulated: No
• Slender Flange Model: No
• With Sight-Hole: Yes
• AWG Size: 000
• Number of Fixing Holes: 1

This crimping lug is ideal for high-performance electrical applications, ensuring durability and a secure connection.
