Copper Tube Terminal 16mm X M12 Hole

A 16mm x M12 hole copper tube terminal is a type of electrical connector that is used to connect copper tubing to electrical equipment. It is made of high-quality copper and is designed to be both reliable and safe. The terminal has a 16mm opening that is compatible with 16mm copper tubing. The terminal also has an M12 hole that is compatible with M12 bolts. This type of terminal is commonly used in electrical distribution systems, such as switchboards and panelboards. All terminals are manufactured from 99.5% copper and fully annealed to ensure optimum ductility to avoid severe deformation such as cracking and splitting when crimped. Terminals are supplied with an inspection window, enabling the user to ensure full and correct insertion of the conductor, while a flared entry ensures a smooth transition from terminal to conductor. Internal barrel diameters suit standard cables as defined in BS 6360. All SWA terminals are identified on the palm with cable size (and stud hole size) to ensure correct selection of the appropriate tool and dies.

Technical Specifications

Download Product Technical Data Sheet

• Material: Copper
• Connecting angle: 90°
